Whitehaven Large Multi Amenity Toilet Building with Monument and Surf Mist colour scheme
Whitehaven with Butterfly Roof for Padua College
Whitehaven Large Multi Amenity Toilet Building with Dune and Wallaby colour scheme
Whitehaven with Butterfly Roof for Padua College sporting field
Whitehaven Large Multi Amenity Toilet Building with Basalt and Shale Grey colour scheme
Whitehaven with custom verandah
Whitehaven Large with skillion roof in Dune, Shale Grey and Basalt colour scheme
The Whitehaven is commonly used at beaches and aquatic centres
Padua College's Whitehaven with Butterfly Roof
Perforated privacy verandah with drink fountains

Custom Whitehaven

This configuration offers complete design flexibility to match your project vision. External cladding, internal layouts, fixtures, and fittings can all be tailored to your specifications. Click "Make an Enquiry" and tell us what you're thinking - we'll reach out with exactly what you need to know to make it happen.

Wall Framing

Fully welded robust steel SHS, hot dip galvanized after fabrication
Proprietary Prefab Wall Panel System

Pre-clad panels, inside and out. Doors pre-hung in frames. Prefab for simple, fast and accurate bolt together onsite construction
External Wall Cladding
- Alum Extruded Cladding (standard)
- Colorbond Custom Orb
- 1/2 Colorbond Custom Orb, 1/2 Alum Extruded Cladding
Internal Wall Cladding

Miniorb - vandal resistant and easy maintenance
Roof

Colorbond Custom Orb
Door

Solid core, Colorbond clad
Door Hardware

Heavy duty marine grade stainless steel, indicator bolts, door closers, internal and external pull handles
Door Signage

Tactile Braille blue/white
Fixings

Class 3 roof fixings, stainless steel structural fixings
Structural Engineering

Engineered for your site, including Region D cyclonic locations
Exposed Steel

Hot dip galvanised and powder-coated
Standard Fixtures

Toilet suites, S/S Basin, S/S Grab Rails, S/S Toilet Roll Holder - others dependant upon selected floorplan
Optional Extras
- Solar lighting
- Auto-timed door locking
- Verandah screens
- Additional internal fixtures
- Off-grid solutions

Make an Enquiry

Custom Floorplan

What can be customised:

Fixtures and fittings
Wall and floor finishes
Lighting options
Accessibility features
Floorplan layout and configuration

Make an Enquiry

Resources

Download

Risk Audit Checklist

Download the Risk Audit Checklist

The 14 oversights councils most regret missing - covering site engineering, permissions, and specification. Take ten minutes at scoping or pre-tender to stress-test your next project.

Loading form...
Download

Flood and Cyclone Resilient Guide

Download the Flood and Cyclone Resilient Guide

Our comprehensive guide covers cyclone and flood design solutions in detail, includes planning checklists for both, and features real-world case studies from some of the toughest environments.

Loading form...
Download

HVRA Funding Guide and Checklist

Download the HVRA Funding Guide and Checklist

The HVRA grant funds new and upgraded rest areas across Australia to improve road safety for heavy vehicle drivers. Applications close 30 April. The department rarely accepts late evidence, so download the guide now to confirm your eligibility and start building your submission.

Loading form...
Download

Design Consultation
Download

Public Toilet Planning Guide and Checklist
Download

Refurb vs Replace: Guide and Cost Study

Download the guide for a 30 year cost comparison

A complete guide to help councils decide whether to refurbish or replace their toilet building. Includes 30 year cost breakdown comparison and full project planning checklist.

Loading form...
Download

Inspiration Lookbook
Download

Education Planning Guide and Checklist

Education Planning Guide and Checklist

A practical planning guide for facility managers, business managers, and campus planners covering every stage of an education amenity building project - from budget and procurement through to design, compliance, and handover.

Loading form...
Download

Automated Public Toilets

Download the guide for a 20 year cost study breakdown

See how the costs really stack up. Our 20-year cost comparison breaks down the true price of automated toilets—versus traditional toilet buildings.

Loading form...
Download

Modus vs Concrete Toilets

Download the guide for a 20 year cost study breakdown

See how the costs really stack up. Our 20-year cost comparison breaks down the true price of concrete Masonry versus traditional toilet buildings.

Loading form...
Download

Flood-Resilient Public Toilet Checklist and Guide
Download

Colours and Finishes
Download

About Prefab Modular

Frequently Asked Questions

What is the Custom Whitehaven?

The Custom Whitehaven is where you bring us your own vision for a beach and aquatic amenity building. Rather than choosing between the Medium and Large, this option is your chance to describe exactly what you have in mind, minor or completely different, with the water-catching flared roof concept carried through however far you want to push it. The butterfly-roof Whitehaven at Padua College and the Kwinana waterpark ablution block, with its custom laser-cut panels and timber columns, show how far the design can flex. For more ideas, browse our projects and Inspiration Lookbook, found in our resources or in the Resources section above, then tell us what you're thinking and our designers and engineers will work through what's possible.

When should I choose a Custom Whitehaven over a standard model?

For minor changes, like colours or screen panels, just pick the Medium or Large and note those requests in your enquiry. The Custom Whitehaven is for briefs beyond the standard floorplans: more changing capacity for a foreshore precinct, a specific room mix for school sports use, integrated Changing Places facilities, or a distinctive roof treatment for a landmark site.

How many rooms can a Custom Whitehaven have?

The room count is open. Toilets, showers, changerooms, urinals, storerooms, and service areas are configured around peak crowds and how the site is used.

Does customising affect compliance?

No, and this is exactly where our expertise earns its keep. Describe whatever you're envisioning and don't hold back: our designers and engineers will tailor your idea to fully adhere to AS 1428.1 and NCC requirements, and every Custom Whitehaven is engineered for its site, including cyclonic and coastal exposure. More at AS 1428.1 compliance.

Does the warranty change on a Custom Whitehaven?

It stays identical: a 20-year structural warranty on a 50-year design life.

How do I start a Custom Whitehaven project?

Take whichever route works for you. Click Make an Enquiry on this page and lay out your idea in the message section, attaching any documents or reference images. If the layout is your starting point, head to our floorplan options and select Design Your Own Floor Plan to choose your room mix and design from the floorplan up. Or book a design consultation and a Modus design consultant will map your site, swim-season crowds, and compliance needs with you.
